PUMA 2100Y II
The PUMA 2100Y II is a horizontal turning center for machining a wide range of metal components. It provides a maximum turning diameter of 406 mm and a turning length of 520 mm, with a 203 mm chuck. A 12-station turret supports sequential machining operations. Live tooling and 105 mm of Y-axis travel enable off-center milling and drilling in a single setup.
PUMA 2100Y II
Technical specifications
| Chuck size | 203 mm |
|---|---|
| Max. turning diameter | 406 mm |
| Max. turning length | 520 mm |
| X-axis rapid traverse | 30 m/min |
| Z-axis rapid traverse | 30 m/min |
| X-axis travel | 260 mm |
| Y-axis travel | 105 mm |
| Z-axis travel | 590 mm |
| Max. spindle speed | 5000 rpm |
| Spindle power | 22 kW |
| Max. spindle torque | 358 Nm |
| Number of tools | 12 pcs |
| Max. tool speed | 5000 rpm |
Dimensions
| Dolžina | 3190 mm |
|---|---|
| Višina | 2163 mm |
| Širina | 1945 mm |
| Masa | 5550 kg |
BTS Company provides complete delivery of CNC machines – from safe transport to full commissioning at the customer's site. Delivery is carried out together with specialised transport partners, and on site we take care of professional unloading. An authorised service team carries out the installation and commissioning in line with the manufacturer's standards. After commissioning we provide operator training, technical support and regular maintenance for reliable and efficient operation of the machine.
