PUMA 700M II
The PUMA 700M II is a horizontal turning center for machining large components and demanding cutting operations. It provides a maximum turning diameter of 900 mm and a turning length of 1600 mm, with a 610 mm chuck. The main spindle reaches speeds of up to 1500 rpm and delivers up to 55 kW, with up to 8076 Nm of torque. Live tooling at up to 3000 rpm combines turning, milling and drilling in a single setup.
PUMA 700M II
Technical specifications
| Chuck size | 610 mm |
|---|---|
| Max. turning diameter | 900 mm |
| Max. turning length | 1600 mm |
| X-axis rapid traverse | 12 m/min |
| Z-axis rapid traverse | 16 m/min |
| X-axis travel | 470 mm |
| Z-axis travel | 1650 mm |
| Max. spindle speed | 1500 rpm |
| Spindle power | 55 kW |
| Max. spindle torque | 8076 Nm |
| Number of tools | 12 pcs |
| Max. tool speed | 3000 rpm |
Dimensions
| Dolžina | 5756 mm |
|---|---|
| Višina | 2800 mm |
| Širina | 3160 mm |
| Masa | 16500 kg |
BTS Company provides complete delivery of CNC machines – from safe transport to full commissioning at the customer's site. Delivery is carried out together with specialised transport partners, and on site we take care of professional unloading. An authorised service team carries out the installation and commissioning in line with the manufacturer's standards. After commissioning we provide operator training, technical support and regular maintenance for reliable and efficient operation of the machine.
