PUMA TL2000M
The PUMA TL2000M is a twin-turret horizontal turning center for productive shaft machining. It provides a maximum turning diameter of 350 mm and a turning length of 600 mm, with a 203 mm chuck. The main spindle reaches speeds of up to 5000 rpm and delivers up to 22 kW. Live tooling complements simultaneous twin-turret operation with milling and drilling in the same setup.
PUMA TL2000M
Technical specifications
| Chuck size | 203 mm |
|---|---|
| Max. turning diameter | 350 mm |
| Max. turning length | 600 mm |
| X-axis rapid traverse | 20 m/min |
| Z-axis rapid traverse | 24 m/min |
| X-axis travel | 250 mm |
| Z-axis travel | 650 mm |
| Max. spindle speed | 5000 rpm |
| Spindle power | 22 kW |
| Max. spindle torque | 476 Nm |
| Number of tools | 12 pcs |
| Max. tool speed | 5000 rpm |
Dimensions
| Dolžina | 3250 mm |
|---|---|
| Višina | 1930 mm |
| Širina | 2118 mm |
| Masa | 7200 kg |
BTS Company provides complete delivery of CNC machines – from safe transport to full commissioning at the customer's site. Delivery is carried out together with specialised transport partners, and on site we take care of professional unloading. An authorised service team carries out the installation and commissioning in line with the manufacturer's standards. After commissioning we provide operator training, technical support and regular maintenance for reliable and efficient operation of the machine.
