PUMA TL2500LM
The PUMA TL2500LM is a twin-turret horizontal turning center for productive shaft machining. It provides a maximum turning diameter of 350 mm and a turning length of 1000 mm, with a 254 mm chuck. The main spindle reaches speeds of up to 4000 rpm and delivers up to 26 kW. Live tooling complements simultaneous twin-turret operation with milling and drilling in the same setup.
PUMA TL2500LM
Technical specifications
| Chuck size | 254 mm |
|---|---|
| Max. turning diameter | 350/240 mm |
| Max. turning length | 1000 mm |
| X-axis rapid traverse | 20 m/min |
| Z-axis rapid traverse | 24 m/min |
| X-axis travel | 250 mm |
| Z-axis travel | 1050 mm |
| Max. spindle speed | 4000 rpm |
| Spindle power | 26 kW |
| Max. spindle torque | 433 Nm |
| Number of tools | 12 pcs |
| Max. tool speed | 5000 rpm |
Dimensions
| Dolžina | 3900 mm |
|---|---|
| Višina | 1930 mm |
| Širina | 2144 mm |
| Masa | 8500 kg |
BTS Company provides complete delivery of CNC machines – from safe transport to full commissioning at the customer's site. Delivery is carried out together with specialised transport partners, and on site we take care of professional unloading. An authorised service team carries out the installation and commissioning in line with the manufacturer's standards. After commissioning we provide operator training, technical support and regular maintenance for reliable and efficient operation of the machine.
